主要技術參數(shù)/Major Technical Parameter:

1、機臺最大外型尺寸/The Biggest Outside Measurement:5460 x 1225x 2600

2、額定壓力/Rated Pressure: 20MPa

3、主振形式/Principal Mode of Vibration:臺模合振/All Units vibration mode

4、振動頻率/Vibration Frequency: 2880~4300次/分(T/M)

5、托板尺寸/Splint Dimension: 900 x 550 x 25mm

6、成型周期/Molding Cycle: 13~16秒/次(S/T)

7、總功率/Gross Power: 17.2kW

8、整機重量/Gross weight: 5.2t

9、制品強度/Produce Strang: 35Mpa-70MPa

10、液壓傳動/Hydraulic Transmission

主要優(yōu)點/Main advantage:

出磚即可碼垛;

為彩色路面的生產(chǎn)量身定造，全自動二次布料，實現(xiàn)了 面料添加自動化，徹底解決使用、維護、清理難的問題。

Lowerator after wet block forming;

Specially for producing all kinds of colorful paving blocks,100% automatic color material feeding system.
